Description

:

The Raptor XDX is at the top of the residential zero-turn category. It has commercial-grade features like a 10-gauge fabricated deck, cast steel deck hangers, vented and toolless removable pulley covers, and reaches up to 8mph with Hydro-Gear® ZT-3100® commercial transmissions. The 5-inch-deep deck allows the XDX to mow through thick grass at top speeds. The heavy-duty XDX is backed by an industry leading 3yr / 300hr warranty and 1yr / 300hr commercial warranty.

 Key Features

• 21.5hp, 23hp & 24hp Kawasaki Engines
• 48″, 54″ & 60” decks
• 8mph mowing speed
• 3-year / 300 hour limited warranty
•  Commercial Grade Deck
• Heavy-duty 11 gauge steel and front bull nose bumper design for unmatched durability. Up to 60” deck sizes available.
•  Extra High-back Seat
• A premium extra high-back seat with armrests.
•  22″ BigBite™ Tires
• More aggressive tire to handle tough jobs.

Features:

• Welded Steel Deck: Fabricated from welded steel, enhancing durability and extending the mower’s lifespan.
• Wider Stance: Designed to offer ample room, contributing to operator comfort during operation.
• SmoothTrak Steering: Precision control system enabling effortless trimming and maneuvering around obstacles.
• Bolstered Seat: Provides a comfortable ride with armrests and airflow to the back, ensuring operator comfort.
• Rubber Floor Mat: Standard on all Raptor models, minimizes vibration on the operator’s feet, enhancing comfort during prolonged use.
• Fabricated Frame: Features a continuous one-piece 1½ inch by 3 inch welded tubular frame for structural integrity and robustness.
• Foot-Operated Deck Lift: Easily adjust the deck height between 1.5″ – 4.5″ with foot operation, facilitating customization during mowing.
• Easy to Service: Maintenance is simplified with features like the flip-up seat pan, removable floor pan, and vented pulley covers, ensuring easy access for servicing.
• Exclusive BigBite Rear Tires: Developed in collaboration with the tire manufacturer, offering enhanced traction and performance.
• Kawasaki® Power: Equipped with a V-Twin Kawasaki® Engine, providing reliable power for efficient operation.

Specification:

• Cutting Width: 60″
• Engine: Kawasaki FR730
• Engine Horsepower: 24 HP
• Transmission: Hydro-Gear ZT-3100® Dual Hydrostatic
• Fuel Capacity: 3 gallons
• Ground Speed (FWD): Up to 8 mph
• Cutting Height: 1.5″ to 4.5″
• Front Tire Size: 13 x 6.5 inches
• Drive Tire Size: 22 x 11-10 BigBite™
• Warranty: 3 Year Warranty (Residential) or 1 Year Warranty (Commercial), 300 hour limit

Engine Details:

• Displacement: 726cc
• Cooling: Air Cooled
• Warranty: 3 Year Limited

Transmission Details:

• Type: Dual Hydrostatic
• Technology: Hydro-Gear ZT-3100®
• Warranty: 3 Year Limited

Additional Features:

• Steering: Integrated with steering levers
• Cutting Width: 60″
• Seat: Bolstered extra high-back seat with armrests and built-in lumbar support
• Front Tire Size: 13 x 6.5 inches
• Drive Tire Size: 22 x 11-10 BigBite™
• Weight: 710 lbs
• Height: 43.7 inches
• Length: 71.1 inches
• Width w/ Chute Up: 62.2 inches
• Tire-to-Tire Width: 48.6 inches
• Productivity (Acres per Hour): 3.88

Warranty:

• Residential: 3 Year/300 hour
• Commercial: 1 Year/300 hour

Bagging Systems:

• 60″ Model: Powered 2-bag, 7.2 bushel capacity
• Dimensions: 92.3″ (Width) x 69.2″ (Height)
